Voyager F
¥8.8 million
Voyager F
Specifications:
Length:11650mm
Width:2545mm
Height:3995mm
Chassis:SCANIA P500 6X6
Weight:21000kgs
Fuel capacity:Dual fuel tank, 400 + 400 = 800 liters total
Transmission:SCANIA GA867 (Allison)6 speed automatic
Power output:500 hp
Torque output:2550 Nm
Tyres:Michelin 395/85 R20 xzl
Drivetrain:Full-time 6 wheel drive,with locking differentials on each axle and 2 locking inter-axle differential
Driver cabin:genuine leather upholstery, seats for 4 persons
Emission standard:Euro VI
Color: customizable
Engine:Scania inline 6 cylinder, common rail diesel
Features:
Front section:6 seat U shaped sofa/dinette with height adjustable table. Additional bunk over sofa area(2000 by 1750 mm)
Mid section:Galley, shower and bathroom
Rear section:bedroom, twin bed 2,000 by 1,400 mm
Second story:electrically actuated lift deck, offers a patio deck across the rear section of the camper
Maximum sleeping accommodation:6 persons
Second story features:
Yacht style patio deck
U shape sofa, height adjustable table, teak flooring
Kitchenette sink, induction cooktop
Projector and motorized screen
Protective railing
Shell and Construction:
ARMADILLO proprietary 3 point floating subframe system
Thermal bridge free sandwich panel body
Window:ARMADILLO proprietary carbon fiber window system with marine grade shades and bug net
Sunroof:ARMADILLO proprietary carbon fiber window system, with marine grade shades and bug net
Main Entry: ARMADILLO proprietary door system, with bug net, electric locking system, PIN or card access.
Entry steps: aluminium 3-step automatic, Armadillo in-house constructions
Marine grade teak flooring with anti-slip rubber strips
Electrical system:
Armadillo automatic high output hybrid power system
8kw low noise water cooled diesel generator set
Victron 8kVa smart inverter/charger
Victron system monitoring and control system
Victron battery combiner/isolator
BEP circuit breaker board
24V Lithium iron phosphate battery packs:1380Ah (230X6)
Shore power charging port and external mains power out socket
Emergency power off switch
24V LED interior lighting/switch (*China spec wall outlet)
Heating, Ventilation and Air Conditioning:
2x 2600 watt air conditioner
Positive pressure ventilation system with pollen filtration, exhaust system
Bedroom radiator heating
Bathroom radiator heating
Webasto 4kW diesel air heater
Water and plumbing:
800 liter stainless steel fresh water tank
Fully automatic fresh water pump
Pressured water fill port with filtration system. External water outlet
9kw diesel coolant heater
40L water heater
Kitchenette equipment:
Flush install refrigerator 259L(186L fridge +73L freezer)
induction cooktop, ARMADILLO custom hood vent
Flush install steamer, convection and microwave combo
Flush install espresso coffee machine
complete set kitchenware and tableware
Bathroom:
separate shower and bathroom
bathroom ventilation system
thermostatic shower system
ceramic electrically operated toilet
waste system: 110L stainless steel greywater tank, 110L stainless steel blackwater tank, electric waste pump
front load washing machine
Entertainment system:
lift-up TV backdrop in bedroom
stationary TV backdrop in sofa area
Satellite TV receiver system
Other features:
Aluminium construction driver cabin rollcage
Natural latex + 3D sofa cushion and mattress
ham radio system
Back-up camera
Surveillance camera system
Pass-thru entry between camper and driver cabin
Floor heating
Optional features:
18500lb rear winch
Solar charge system(flexible solar panel 100Watt x 16)
additional protective railing
Dual radio
outdoor kitchen
electric lifting motorcycle rack
equipment case on top of driver cabin
stereo speaker system
side awning
